Click Any Photo to Enlarge
No ignition components are included, however an aftermarket ignition amplification unit with built in retard capability (such as a Crane HI-6/7 or MSD 6/7) is suggested.
INCLUDED COMPONENTS:
- V-7 YS-Trim supercharger with 10-rib 3.33" pulley to produce approximately 8-10 psig on a stock engine at factory redline
- Supercharger drive assembly includes aluminum 6.88" 10-rib crank pulley with underdrive accessory drive
- Supercharger and accessory drive belts with tensioner assemblies
- T-Rex inline fuel pump with wiring harness, hoses and fittings
- 12:1 FMU with stainless steel braided lines
- Cast aluminum mounting bracket with all necessary hardware
- 6061-T6 billet aluminum 1/2" thick mounting plate with anodized finish
- Large diameter cast aluminum "race" discharge tube assembly with clamps, silicone sleeves and integrated bypass flange
- Maxflow race bypass valve with hose connection, gasket, hardware and clamps
- Complete air inlet assembly with "inner-fender" mounted MAF relocation and cast aluminum 4" elbow at supercharger entry
- Oil drain assembly
- Oil feed assembly with stainless steel braided feed hose
